    S8 Interface LCD Display Module 160 x 64 Resolution Super Twisted Nematic Gray

    Ask Lasest Price
    Brand Name : Elite Tree
    Model Number : ET10064-G01
    Certification : ISO9001:2015 / ISO14001
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 100Kpcs~ per month
    Delivery Time : 5days for sample and 20-25 days for mass production
    • Product Details
    • Company Profile

    S8 Interface LCD Display Module 160 x 64 Resolution Super Twisted Nematic Gray

    LCD Module COG 160*64 Resolution LCD Display Modules STN Gray Reflective Positive


    LCD Display Module


    Product Information


    Display TypeCOG STN Gray Reflective Positive Screen
    Outline dimension43.20mm * 36.00mm * 2.80mm
    Active area
    40.60mm * 26.00 mm
    Interface
    4-wire serial bus(S8)
    Power supply(typ)3.3 V
    Driver ICUC1601S
    Operating temp
    -20ºc~70ºc
    Storage temperature-30ºc~80ºc
    If accept customizedYes
    RoHS complianceYes

    Our advantages


    1) Small quantity accepted
    2) Competitive price and short lead-time and best service
    3) ROHS/ ISO 14001 and other related certificates are available
    4) Reply the mail within 24 hours


    ​Application


    Autoelectronics, 3D&Shutter, Meters & Instrument, Telecommunication,

    Domestic electrical appliance(Household appliance), Fuel dispensers,

    Office equipment, Medical &health equipment, Business related facility, Education electronics, etc.


    Product Drawing
